HOWO TX-N 4X2 Stake Truck

Home / Trucks / Cargo Trucks / HOWO TX-N 4X2 Stake Truck

Model

HOWO TX7-N
Drive Type

4X2
Engine Model

MC07H.35-61
Horsepower

350 HP

overview

The HOWO TX-N 350HP 4X2 Stake Truck is a heavy-duty cargo vehicle from SINOTRUK, designed for agricultural product transport and general logistics. It combines the proven MC07H engine with an AMT transmission and a stake body, offering a practical solution for regional distribution and green-channel operations.

⚡ Powertrain & Performance
- Proven Engine: The MC07H.35-61 is a 7.36L inline-6 diesel producing 1400 N·m of torque across a broad 1200–1700 rpm band, providing strong pulling power for fully loaded operations .
- 12-Speed AMT: The HW12712ACL automated manual transmission reduces driver fatigue on long hauls and optimizes shift points for fuel efficiency.
- Heavy-Duty Axles: Features a 1094Q front axle and MCJ09BGQ rear axle with a 3.91 ratio, balancing load capacity with highway fuel economy.

Specifications

HOWO TX-N 4X2 STAKE CARGO TRUCK
Type:	Stake Cargo Truck
Drive Type:	4X2
Rear Axle Ratio:	3.91
Tonnage Level:	Heavy Truck
Energy Type:	Diesel
Engine Model:	MC07H.35-61
Engine Info:	China National Heavy Duty Truck 7.4L
Number of Cylinders:	6 cylinders
Fuel Type:	Diesel
Cylinder Arrangement:	Inline
Displacement:	7.36L
Emission Standard:	China VI
Maximum Output Power:	254kW
Maximum Horsepower:	350 hp
Maximum Torque:	1400 N·m
Maximum Torque RPM:	1200-1700 rpm
Rated RPM:	2200 rpm
Engine Type:	Inline six-cylinder, water-cooled, four-stroke, turbocharged with intercooler, high-pressure common rail
Transmission Model:	HW12712ACL
Shift Type:	AMT automated manual transmission
Forward Gears:	12 gears
Reverse Gears:	2 units
Cargo Box Type:	Stake style
Seating Capacity:	2 people
Number of Seat Rows:	Single cab
Driver Seat Type:	Air suspension seat
Front Axle Description:	1094Q front axle
Frame Dimensions:	6/232mm
Rear Axle Description:	MCJO9BGQ
Gear Ratio:	3.91
Number of Leaf Springs:	7/7+3
Frame Type:	Single-layer chassis

🛋️ Cabin & Comfort
- Air Suspension Seat: The driver’s seat features air suspension to reduce fatigue during long working hours .
- Practical Amenities: Includes automatic air conditioning, power windows, electric heated mirrors, remote key, and electronic central locking.
- Multimedia: Equipped with a color central control screen, Bluetooth phone connectivity, and reversing camera.

Interior

Excellent Ergonomic Design

All controls, instrument panels, and displays are intuitively arranged for easy access and quick information retrieval, minimizing distractions and maximizing driver focus. The pneumatically controlled steering wheel is fully adjustable for both height and angle.
High Comfort

Featuring an adjustable air suspension seat, the HOWO-TX offers multi-directional electric adjustment and lumbar support, allowing drivers to personalize their seating for optimal comfort. Crafted from high-quality, breathable materials, the seat effectively reduces fatigue during long drives.
All-Around Vision, Everything in Sight

Featuring wide-view design, four-way monitoring system (optional), and observation window (optional), the driver is accessible to comprehensive visual information about the surrounding environment and traffic dynamics of the vehicle, thus making accurate assessments, and safely responding to various situations.
Strong Power, Efficient and Reliable

Meticulous design and optimization of the HOWO-TX powertrain, combined with careful component matching and integration, delivers seamless power transmission, maximized efficiency, enhanced vehicle performance, and significantly reduced fuel and maintenance expenses.
