HOWO TX 6×4 Pure Electric Tractor

Home / Trucks / Electric Trucks / HOWO TX 6×4 Pure Electric Tractor

HOWO TX 6×4 Pure Electric Tractor

Model

ZZ4257Y344GZ1BEV42
Energy Type

Pure electric
Max Towing Mass

3.775 tons
Wheelbase (mm)

7080 × 2520 × 3135

overview

The HOWO TX 6×4 Pure Electric Tractor is a heavy-duty, zero-emission truck designed by Sinotruk for port operations, steel mills, and regional short-haul logistics. It combines the proven TX-F cab with a powerful central-drive electric powertrain and CATL lithium iron phosphate battery technology.

Battery & Charging
- Battery Brand: CATL (Ningde Times)
- Battery Type: Lithium Iron Phosphate (LFP)
- Battery Capacity: Available in 423 kWh and 400.619 kWh configurations
- Rated Voltage: 618.24 V
- Energy Density: 161.27 Wh/kg
- CLTC Range: Approximately 270 km (with 423 kWh battery)

Specifications

HOWO TX 6×4 PURE ELECTRIC TRACTOR
MIIT Model No.	ZZ4257Y344GZ1BEV42
Brand	SINOTRUK HOWO
Model	TX 6×4 Pure Electric Tractor
Drive Type	6×4 (10 wheels)
Overall Dimension (L×W×H)	7080 × 2520 × 3135 mm
Wheelbase	3425 + 1350 mm
Curb Weight	11050 kg
Gross Vehicle Mass(GVM)	25000 kg
Max Towing Mass	37750 kg
Max Speed	89 km/h
Battery Type	LFP Lithium Iron Phosphate (CATL)
Battery Capacity	422.87 kWh (423kWh)
Motor Type	Permanent Magnet Synchronous Motor
Peak Power	520 kW
Rated Total Power	280 kW
CLTC Range	270 km
Charging Mode	DC fast charging
Cab	HOWO TX air suspension cab
Steering	LHD / RHD optional

Powertrain & Electric Motor
- Motor Type: Permanent Magnet Synchronous Motor (PMSM)
- Motor Model: TZ230XS-ZQRM130V08 / TZ230XS-ZQRM130V09 (dual-motor configuration)
- Rated Power: 280 kW
- Peak Power: 520 kW
- Max Torque: 900 N·m

Interior

Excellent Ergonomic Design

All controls, instrument panels, and displays are intuitively arranged for easy access and quick information retrieval, minimizing distractions and maximizing driver focus. The pneumatically controlled steering wheel is fully adjustable for both height and angle.
High Comfort

Featuring an adjustable air suspension seat, the HOWO-TX offers multi-directional electric adjustment and lumbar support, allowing drivers to personalize their seating for optimal comfort. Crafted from high-quality, breathable materials, the seat effectively reduces fatigue during long drives.
All-Around Vision, Everything in Sight

Featuring wide-view design, four-way monitoring system (optional), and observation window (optional), the driver is accessible to comprehensive visual information about the surrounding environment and traffic dynamics of the vehicle, thus making accurate assessments, and safely responding to various situations.
Strong Power, Efficient and Reliable

Meticulous design and optimization of the HOWO-TX powertrain, combined with careful component matching and integration, delivers seamless power transmission, maximized efficiency, enhanced vehicle performance, and significantly reduced fuel and maintenance expenses.
