Model
SX4259GD4Q2
Engine model
WP13H560E68A
Total traction mass
40 tons
Wheelbase
3450+1350mm
The Shacman X6000 6×4 tractor truck with 560HP (Model: SX4259GD4Q2) is a flagship heavy-duty vehicle engineered for high-performance long-haul transportation. It combines robust power, fuel efficiency, and advanced safety features, designed to meet global standards for demanding logistics operations across diverse terrains. As a flagship 6×4 model in the X6000 series, it is powered by a Weichai WP13H560E68A engine producing 560HP and 2585N·m of torque, paired with a Fast S16AD 16-speed AMT transmission.
The X6000 560HP is powered by the Weichai WP13H560E68A, a 12.9L inline-six diesel engine delivering 560HP (412 kW) and a maximum torque of 2585 N·m at 900–1300 rpm. The low-RPM torque delivery ensures strong climbing ability and reduced fuel consumption during highway cruising.
The engine is paired with the Fast S16AD 16-speed AMT transmission featuring predictive shifting, which adapts to road conditions and load weight, minimizing driver intervention and improving gearshift precision. The rear axle ratio of 2.643 is optimized for highway fuel economy.
| SHACMAN X6000 6X4 TRACTOR TRUCK | |
| Model: | SX4259GD4Q2 |
| Drive type: | 6X4 |
| Wheelbase: | 3450+1350mm |
| Engine: | WP13H560E68A |
| Transmission: | Fast S16AD |
| Rear axle ratio: | 2.643 |
| Vehicle length: | 7.08 meters |
| Vehicle width: | 2.55 meters |
| Vehicle height: | 3.8 meters |
| Front track: | 2070mm |
| Rear track: | 1880/1880mm |
| Total vehicle weight: | 8.87 tons |
| Total mass: | 25 tons |
| Total traction mass: | 40 tons |
| Maximum speed: | 89km/h |
| Tonnage class: | heavy trucks |
| Energy type: | diesel fuel |
| Engine model: | WP13H560E68A |
| Engine brand: | Weichai |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | Inline |
| Displacement: | 12.9L |
| Emission standards: | National VI |
| Maximum horsepower: | 560 Horsepower |
| Maximum output power: | 412 KW |
| Maximum torque: | 2585N·m |
| Maximum torque speed: | 900-1300rpm |
| Rated speed: | 1600rpm |
| Transmission model: | Fast S16AD |
| Gearbox brand: | Fast |
| Gear shifting method: | AMT Hand-in-hand |
| Forward gear: | 16 gears |
| Number of reverse gears: | 2 |
| Driver’s cab: | High Top |
| Fuel tank/gas cylinder material: | Aluminum alloy |
| Fuel tank capacity: | 1000L |
| Cab suspension: | Four-point airbag suspension |
| Passenger capacity: | 2 people |
| Cab lifting: | electric |
| Driver’s seat configuration: | Airbag suspension seat |
| Front axle description: | SHF-7.3 |
| Rear axle description: | SHR-13 Single Level |
| Front axle allowable load: | 7000kg |
| Speed ratio: | 2.533 |
| Suspension method: | 18000(Two-axis group) |
| Number of leaf springs: | 2\4 |
| Saddle: | 90 |
| Number of tires: | 6 |
| Tire specifications: | 295-80R22.5 |
The X6000 features a high-roof cab with four-point airbag suspension, designed for long-haul driver comfort. Key features include:
Noise Insulation: Cab interior noise reduced to ≤72 dB
Spacious Bunk Area: Reduces fatigue during multi-day trips
Driver’s Seat: Airbag suspension seat with multiple adjustments
Cab Suspension: Four-point airbag suspension system
Cab Lifting: Electric operation
The X6000 560HP tractor truck is engineered for:
Intercity Long-Haul: Transporting containers, bulk cargo, and industrial goods between major logistics hubs
Specialized Cargo: Suitable for oversized/heavy equipment transportation with optional trailer compatibility
Highway Logistics: Optimized for highway speeds (max 89 km/h) with aerodynamic design to reduce wind resistance
