Vehicle type
Refrigerated truck
Engine model
YC4EG185-50
Rated load
10.565 tons
Body dimensions (m)
9.15×2.56×3.995
The Shacman L3000 4×2 Refrigerated Truck is a medium-duty cold-chain vehicle built on the proven L3000 chassis platform. It is designed for urban distribution and short-to-medium-haul transport of temperature-sensitive goods, including fresh produce, dairy, frozen foods, and pharmaceuticals.
The truck is powered by a Yuchai YC4EG185-50 diesel engine, a 4.73L inline-4 unit with BOSCH high-pressure common rail injection, producing 185 HP (136 kW) and 700 N·m of torque. A Weichai engine option is also available for export markets. Transmission choices include a WLY 6-speed manual or a Fast 8-speed manual, paired with a 4.8T front axle and an 8T or 10T single-reduction rear axle. The 4×2 drive configuration and 10.00R20 tires ensure reliable traction and load distribution.
| SHACMAN L3000 4X2 REFRIGERATED TRUCK | |
| Body dimensions: | 9.15×2.56×3.995 meters |
| Drive type: | 4X2 |
| Vehicle type: | Refrigerated truck |
| Wheelbase: | 5000mm |
| Front overhang / Rear overhang: | 1.34/2.81 meters |
| Curb weight: | 1.24 tons |
| Rated load: | 10.565 tons |
| Top speed: | 100km/h |
| Energy type: | Diesel |
| Front track: | 1935mm |
| Rear track: | 1860mm |
| Engine model: | Yuchai YC4EG185-50 |
| Number of cylinders: | 4 cylinders |
| Maximum output power: | 136kW |
| Maximum horsepower: | 185 HP |
| Displacement: | 4.73L |
| Emission standard: | China V |
| Fuel type: | Diesel |
| Rated speed: | 2500rpm |
| Engine type: | BOSCH high-pressure common rail |
| Maximum torque: | 700N·m |
| Cabin: | Delong L3000 cab |
| Chassis brand: | Shaanxi Heavy Duty Truck |
| Chassis series: | Delong L3000 |
| Chassis model: | SX1180LA12 |
| Frame dimensions: | 870X230mm |
| Front axle description: | 4.8T MAN |
| Rear axle description: | 8T Zoomlion single-drive reducer axle |
| Gear ratio: | 4.875 |
| Number of leaf springs: | 10/9 6,3/4 3,3/3 2 |
| Tire specifications: | 10.00R20 |
| Number of tires: | 6 units |
The refrigerated box can be equipped with cooling units from Thermo King (e.g., T-600M), Carrier (e.g., D6), or equivalent domestic brands. It maintains temperatures ranging from -25°C to +15°C, with dual-temperature control options available for transporting different goods simultaneously. The insulated cargo box features food-grade FRP skins and polyurethane foam insulation at 85–105 mm thickness.
